The best is built in with McKee Homes in Every Home
All homes are constructed to Energy code 9.36 under the performance modeling guideline. Each home we build is modelled to the site it is built on, and after constructed, is individually tested and certified with Built Green.
Every home is BUILT GREEN and Energuide Certified.
- 2” x 6” exterior wall construction; 24” on center with 3/8” OSB
- 18” x 6’ footings with 8” thick concrete foundation walls
- Delta MS foundation wrap
- Tyvek house wrap
- Envelope sealant membrane around windows and doors
- R20 exterior wall insulation (PROPEL), R22 exterior wall insulation (SIGNATURE)
- 4” thick floating slab garage floor
- Ice dam protection on perimeter of roof with galvanized steel drip edge
- Pre finished aluminum eavestroughs and downspouts
- Pre finished concrete front step with aluminum picket
- Vinyl TRIPLE glazed windows, ENERGY STAR rated; upper floor, main floor, walkout basement
- Vinyl double glazed windows; basement
- Low expansion foam insulation on joist ends, around windows and bonus room floors that are over a garage
- R50 loose fill ceiling insulation
- The Energy Heel: 14” high heel roof trusses (allows attic insulation to reach R50 at the walls, versus 4.0’ in from the walls like in traditional construction)
